110H/60V View Angle Stage LED Screens For Sports Hall

large.img.alt
small.img.alt

Large Image :  110H/60V View Angle Stage LED Screens For Sports Hall Get Best Price

Product Details:
Place of Origin: Shenzhen
Brand Name: Eachin
Certification: CE, RoHs, ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Packaging Details: Plywood or Flight case
Delivery Time: 10-15 days
Payment Terms: T/T,L/C
Supply Ability: 5000sqm/month
Detailed Product Description
Pitch/mm: P20 Viewing Distance: ≥17
View Angle / °: 110 H, 60 V Driving Method: Constant Current
IP Rating: IP65 , IP44 Input Signal: RGBH, YUV, YC
High Light:

outdoor led display screen

,

led video screen



110H/60V View Angle Stage LED Screens For Sports Hall





Specifications:



Outdoor full color Video Display

Module

Pitch/mm

p10

p12

p16

p20

Module size/mm

160x160

192x192

256x128

320x160

Density of pixel/(dots/m2)

10, 000

6, 944

3, 906

2, 500

Pixel composition

1R1G1B

2R1G1B

2R1G1B

2R1G1B

Led encapsulation

DIP

DIP

DIP

DIP

Resolution of module

16X16

16X16

32X16

32X16

Main

Optimum viewing distance

≥10

≥12

≥15

≥17

View angle / °

110 H, 60 V

110 H, 60 V

110 H, 60 V

110 H, 60 V

Average power consumption/W/M2

450

450

400

350

Max power consumption/W/M2

950

950

900

850

Size of cabinet/mm

960X960

960X960

1024X768

1280X960

Resolution of cabinet

96X96

80x80

64x48

64X48

Weight of cabinet/kg

65

65

60

75

Driving method

1/4 scan constant current

1/4 scan constant current

Static constant current

Static constant current

Frame frequency / Hz/S

≥60

≥60

≥60

≥60

Refresh rate Hz/S

≥600

≥600

≥600

≥600

Luminance of white balance

≥7000 nits

≥7000 nits

≥6500 nits

≥6000 nits

Operation of Environmental Temperature/℃

below 30  to  above 50

IP rating

Front, IP65;Rear, IP43

Working vlotage

110-220 VAC/+/- 10%

Grey scale/color

displaying colors≥16.7M(synchronized)

Brightness adjustment

256 levels of each color(manually), 100 levels of each color(automatically)

Input signal

RF, S-Video, RGB, RGBH, YUV, YC&Composition , etc

Control system

linsn(sending card, receiving cards and Hubs)

Average of non-failure life

>50, 00h

Life span

>100, 000h

Functionaless dot rate

<0.0001





Applications:



This kind of Video Displays are applied for advertising, city beautifying, information publicity, and relative activities.





Application Areas :



·---Outdoor advertising video displays, led video wall, advertising for big companies

·---Sports halls, fields, playgrounds.

·---Airports, bus stations and railway passenger terminals.

·---Facades of shopping malls, department stores, banks and car dealerships.

·---Architecture and social projects, information systems in cities.

·---Highway, road, streets or other public led video display projects.





Competitive Advantage:



1. Quality stability and reliability;

2. High refresh rate and low power consumption;

3. Complete project solution provider

4. Two years warranty
