High Light: | mesh led screen,outdoor led display screen |
---|
P16mm Energy Saving Outdoor LED Screens are perfect for outdoor Advertising.
They enjoy high quality, can save much energy. In long-term prospective, they can save plenty of electricity as well as cost.
Technical Specifications:
P16mm Outdoor Full Color LED Display |
||
Module |
Pitch/mm |
P16 |
Module size/mm |
256x256 |
|
Density of pixel/(dots/m2) |
3,906 |
|
Pixel composition |
1R1G1B |
|
Led encapsulation |
DIP |
|
Resolution of module |
16X16 |
|
Main |
Optimum viewing distance |
≥15 |
View angle / ° |
110 H,60 V |
|
Average power consumption/W/M2 |
400 |
|
Max power consumption/W/M2 |
850 |
|
Size of cabinet/mm |
1024X1024 |
|
Resolution of cabinet |
64x64 |
|
Weight of cabinet/kg |
70 |
|
Driving method |
Static constant current |
|
Frame frequency / Hz/S |
≥60 |
|
Refresh rate Hz/S |
≥600 |
|
Luminance of white balance |
≥6500 nits |
|
Operation of Environmental Temperature/℃ |
below 30 to above 50 |
|
IP rating |
Front,IP65;Rear,IP43 |
|
Working vlotage |
110-220 VAC/+/- 10% |
|
Grey scale/color |
displaying colors≥1.07B(synchronized) |
|
Brightness adjustment |
1024 levels of each color(manually),100 levels of each color(automatically) |
|
Input signal |
RF,S-Video,RGB,RGBH,YUV,YC &Composition ,etc |
|
Control system |
linsn(sending card,receiving cards and Hubs) |
|
Average of non-failure life |
> 50,00h |
|
Life span |
> 100,000h |
|
Functionaless dot rate |
< 0.0001 |
Competitive Advantage:
1. Quality stability and reliability;
2. High refresh rate and low power consumption;
3. Complete project solution provider
4. Two years warranty
