P3.9mm HD High DefinitionIndoor LED Video Walls Smallest Pixel Ptich

large.img.alt
small.img.alt

Large Image :  P3.9mm HD High DefinitionIndoor LED Video Walls Smallest Pixel Ptich Get Best Price

Product Details:
Place of Origin: Shenzhen,China
Brand Name: Eachinled
Certification: CE ROSH,CCC
Model Number: P3.9/P4.8
Payment & Shipping Terms:
Minimum Order Quantity: 6 Square Meters
Price: USD 0-2250 Per Square Meter
Packaging Details: Flight Case/Road Case Size:1.05x0.59x0.55m
Delivery Time: 7-20 Days
Payment Terms: L/C, D/A, D/P, Western Union, T/T, MoneyGram
Supply Ability: 5000 Square Meter Per Month
Detailed Product Description
Cabinet/Panel Size: 500x500x70mm Weight Of Each Panel/Cabinet: 8kg
Panel/Cabinet Material: Die Casting Aluminum Brightness: 1500nit Per Square Meters
SMD Type: SMD2121 Black LEDs View Angle: 140H 120V
High Light:

led video wall rental

,

led video wall display



P3.9mm HD High DefinitionIndoor LED Video Walls Smallest Pixel Ptich





[Product Description]



Indoor High Precision Aluminum Series for Rental:

1. High precision workmanship, seamless splice<0.1mm.

2. High definition visual effect as TV, good for any indoor rental application.

3. No fans no flat cable design, no noise, easy to disassembly.

4. Snap joint mask design, more easier to insallation, less maintenaince cost.

5. Adopt high quality SMD2121 or SMD3528 LED as light source.

6. Assure consitent color temperature and brightness.



[Technical Specification]



Pixel Pitch

3.9mm

4.8mm

5.2mm



LED type

RGB 3in1 SMD2121

RGB 3in1 SMD2121          SMD3528



Pixel Density(dot/s.q.m)

65536

43402

36884



Resolution(WxH)

128*128dot

104*104 dot

192*96dot



Cabinet size

500x500x70mm



Weight

8kg

8kg

8kg



Waterproof rate

IP43



Brightness

1200nits

1200nits

2000nits



View Distance

4m

5m

5m



Viewing Angle (H/V)

140°/12

Gray Scale

14bit

Color type

68 Billion

Max.Power Consumption

250W/PCS

120W/PCS

120W/PCS



Ave .Power Consumption

130W/PCS

60W/PCS

60W/PCS



Refresh rate

1960Hz

Gamma

-5.0~+5.0

Applied environment

INDOOR



Controller

Synchronous display with control PC by DVI

Support Input

Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI

Power input

AC 110-220V±10%

Environment

temperature -10°C~+50°C,humidity 10~90% RH

Operating Life

50,000hours







[FAQ]



Q1: What's the pixel pitch for Indoor LED Display Screen ?

A1: Indoor (3.9mm / 4.8 mm/ 5.2mm)



Q2: Where is it used for?

A2: Indoor & rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.

Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling system.



Q4: What's the controlling system?

A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.



Q5: How about the size of project?

A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
